Nitrogen Hoses
Nitrogen hoses are a fundamental necessity across diverse industrial applications, guaranteeing secure and productive nitrogen gas conveyance. Our top-notch hoses are meticulously crafted for both endurance and adaptability, making them indispensable in critical sectors like chemical manufacturing, food processing, and beyond. Nitrogen hoses are vital for safe and efficient nitrogen gas transport.
| Certifications | |
|---|---|
| EN ISO 1307:2008 | Constructions |
| Material of the inner wall | Thermoplastic elastomer |
| Type of inner wall | Smooth |
| Color of the inner wall | Black |
| Material of the outer wall | Thermoplastic elastomer |
| Outer wall | Smooth |
| Color of the outer wall | Yellow |
| Resistance of the outer wall | UV resistant |
| Reinforcements | Textile reinforcements |
| Physical properties | |
| Operating pressure at 20°C | 20.0 bar |
| Burst pressure | 60 bar |
| Minimum temperature | -20°C |
| Maximum temperature | +60°C |
| Artikel number | Ø Inw. (mm) | Wand (mm) | Ø Uitw. (mm) | Bending radius (mm) | Weight (kg/mtr) | Length m |
|---|---|---|---|---|---|---|
| 3202013023 | 13,0 | 5,0 | 23,0 | 105 | 0,385 | 40 |
| 3202019031 | 19,0 | 6,0 | 31,0 | 150 | 0,610 | 20/40 |
| 3202025039 | 25,0 | 7,0 | 39,0 | 200 | 0,880 | 40 |
