| Specification | Temperature |
|---|---|
| EPDM™ | -51.1 (-60) to +137.8 (+280) °C (F°) |
| PTFE | +4.4 (+40) to +104.4 (+220) °C (F°) |
| NBR | -12.2 (+10) to +82.2 (+180) °C (F°) |
Atex air powered Diaphragm pump 2.
Experience secure and efficient fluid transfer solutions with the advanced LTT ATEX Air-Powered Diaphragm Pump 2. Our state-of-the-art technology ensures precise and dependable fluid pumping, serving as an essential component for transferring fluids in various industrial applications, even in hazardous ATEX zones. Whether you require robust solutions for ATEX-rated fluid transfer in volatile environments or specialized pumping systems for critical operations, our ATEX Air-Powered Diaphragm Pump 2. consistently delivers unmatched performance, setting new industry standards.
| Specification | Value |
|---|---|
| Construction Material | PE. PTFE |
| Center Section | PE, PTFE |
| Air Valve | PETP |
| Max. capacity | 330 Liters per minute (LPM) or 88 Gallons per minute (GPM) |
| Max pressure | 7 Bar (100 PSI) |
| Max temperature setpoint | 120° C |
| Max. particle size: | 8 mm |
| Air connection: | 13 mm (1/2 inch) |
| Drive type: | Air powered |
| Liquid connections: | 38 mm (1 1/2 inches) |
| Ship weight | PE: 34Kg (75 lbs), PFTE: 69 Kg (152lbs) |
| Max Diameter Solids | 12.7 mm (1/2 inches) |
For the right choice of Diaphragms ←, contact LTT Holland.
